- Codice Macchina
- FL1030
- Manufacturer
- FLEXOTECNICA
- Modello
- TACHYS
- Year
- 2003
- Numero di colori
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 950
- Larghezza stampa (mm)
- 900
- Min print repeat (mm)
- 280
- Max print repeat (mm)
- 650
- Unwinder type
- double bracket unwinder with dancing roller tension control
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret automatic rewinder
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 zones , 4 fans , final tunnel ,Electric Heaters
- Videocamera
- 3chip camera system, with additional inspection unit
- Trattamento Corona
- Yes by AFS
- Guida film
- Yes,BST guide before drum, BST guide before rewinder
- Sistema d'inchiostro
- closed doctor blade chambers , electric ink pumps
- Anilox
- 22
- Maniche stampa
- 236 as follows ( SLEEVES for 1,14 mm plate ) 8 for each following repeat : 280 mm , 290 ,300 , 310 , 320 ,330 ,340 , 350 , 360 , 370 , 380 , 390 , 400 , 420 ,440, 460 , 480 , 500 , 520 , 530 , 540 , 560 ; 6 x 410 ,6x 470 , 6x 570 5x650 ,. Following sleeves for 2,54 mm plate : 6 x 280 mm, 6x 340 , 6x 460 , 6x 500 , 5x 360 , 5x 380 , 5x 400.
- Ulteriori informazioni
- - banana roll - chill roller - 3 zones of tension control - slitting unit - drum temperature controller - gear 10mm step - speed 250m/m, depending on a product - Dimensions: 14480 mm long, 4820 mm height, around 5500mm total width
| Codice Macchina | FL1030 |
| Manufacturer | FLEXOTECNICA |
| Modello | TACHYS |
| Year | 2003 |
| Numero di colori | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 950 |
| Larghezza stampa (mm) | 900 |
| Min print repeat (mm) | 280 |
| Max print repeat (mm) | 650 |
| Unwinder type | double bracket unwinder with dancing roller tension control |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret automatic rewinder |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 zones , 4 fans , final tunnel ,Electric Heaters |
| Videocamera | 3chip camera system, with additional inspection unit |
| Trattamento Corona | Yes by AFS |
| Guida film | Yes,BST guide before drum, BST guide before rewinder |
| Sistema d'inchiostro | closed doctor blade chambers , electric ink pumps |
| Anilox | 22 |
| Maniche stampa | 236 as follows ( SLEEVES for 1,14 mm plate ) 8 for each following repeat : 280 mm , 290 ,300 , 310 , 320 ,330 ,340 , 350 , 360 , 370 , 380 , 390 , 400 , 420 ,440, 460 , 480 , 500 , 520 , 530 , 540 , 560 ; 6 x 410 ,6x 470 , 6x 570 5x650 ,. Following sleeves for 2,54 mm plate : 6 x 280 mm, 6x 340 , 6x 460 , 6x 500 , 5x 360 , 5x 380 , 5x 400. |
| Ulteriori informazioni | - banana roll - chill roller - 3 zones of tension control - slitting unit - drum temperature controller - gear 10mm step - speed 250m/m, depending on a product - Dimensions: 14480 mm long, 4820 mm height, around 5500mm total width |
