COMEXI FP 1808 Macchina da stampa flexo 8 colori

Codice Macchina
FL0873
Manufacturer
COMEXI
Modello
FP 1808
Year
2000
Numero di colori
8
Print possibilityes
8+0
Gearless
No
Cambio a maniche rapido
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Larghezza nastro (mm)
870
Larghezza stampa (mm)
820
Min print repeat (mm)
300
Max print repeat (mm)
700
Unwinder type
Double
Diametro massimo svolgitore (mm)
800
Rewinder type
Turret non stop
Max reel diameter rewinder (mm)
800
Essiccazione
2 zones 4 fans , thermo oil heaters
Videocamera
yes BST
Guida film
Yes in and out
Vyscosity control
Yes by INELME
Sistema d'inchiostro
Closed chaber doctor blades totally 12 ( 8 in machine and 4 spares)
Anilox
12 ceramic sleeves
Maniche stampa
totally 300 sleeves of following repeats : 330/340/350/360/370/380/400/420/440/450/460/470/480/500/520/540/560/580/600/620/640/650 Totally 33 set of gears ( 8 each )
Ulteriori informazioni
Automatic preregister set up with auto gear meshing
Codice Macchina FL0873
Manufacturer COMEXI
Modello FP 1808
Year 2000
Numero di colori 8
Print possibilityes 8+0
Gearless No
Cambio a maniche rapido Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Larghezza nastro (mm) 870
Larghezza stampa (mm) 820
Min print repeat (mm) 300
Max print repeat (mm) 700
Unwinder type Double
Diametro massimo svolgitore (mm) 800
Rewinder type Turret non stop
Max reel diameter rewinder (mm) 800
Essiccazione 2 zones 4 fans , thermo oil heaters
Videocamera yes BST
Guida film Yes in and out
Vyscosity control Yes by INELME
Sistema d'inchiostro Closed chaber doctor blades totally 12 ( 8 in machine and 4 spares)
Anilox 12 ceramic sleeves
Maniche stampa totally 300 sleeves of following repeats : 330/340/350/360/370/380/400/420/440/450/460/470/480/500/520/540/560/580/600/620/640/650 Totally 33 set of gears ( 8 each )
Ulteriori informazioni Automatic preregister set up with auto gear meshing
