- Codice Macchina
- FL834
- Manufacturer
- COMEXI
- Modello
- FJ 2108
- Year
- 2004
- Numero di colori
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1270
- Larghezza stampa (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- Turret semi automatic marriage roll
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret automatic flying splice
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- Gas, between colors and drying tunnel
- Videocamera
- AVT 2009 - camera with dual screens
- Guida film
- BST type OPG before printing and rewinding
- Vyscosity control
- LR products 2004
- Sistema d'inchiostro
- 8 pneumatic reversible ink pumps
- Maniche stampa
- yes
- Ulteriori informazioni
- Speed 300m/min subject to web, materials, printing, inks Electricity 3 x 400 V, 50 Hz Products to be printed Films LDPE 25-150 my, PP, OPP 12-30 my Unwind Turret, marriage roll, dancing roller, tension control, pneumatic shaft 3”and 6” Rewind Turret non-stop, pneumatic shaft 3” Printing unit 8 colours, slow rotation with electrical motors, chamber doctor blades, through off system, meshing system Longitudinal register /side register : Motorized Drive system Bull gear, gear-pitch 5 mm
| Codice Macchina | FL834 |
| Manufacturer | COMEXI |
| Modello | FJ 2108 |
| Year | 2004 |
| Numero di colori | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1270 |
| Larghezza stampa (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret semi automatic marriage roll |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret automatic flying splice |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | Gas, between colors and drying tunnel |
| Videocamera | AVT 2009 - camera with dual screens |
| Guida film | BST type OPG before printing and rewinding |
| Vyscosity control | LR products 2004 |
| Sistema d'inchiostro | 8 pneumatic reversible ink pumps |
| Maniche stampa | yes |
| Ulteriori informazioni | Speed 300m/min subject to web, materials, printing, inks Electricity 3 x 400 V, 50 Hz Products to be printed Films LDPE 25-150 my, PP, OPP 12-30 my Unwind Turret, marriage roll, dancing roller, tension control, pneumatic shaft 3”and 6” Rewind Turret non-stop, pneumatic shaft 3” Printing unit 8 colours, slow rotation with electrical motors, chamber doctor blades, through off system, meshing system Longitudinal register /side register : Motorized Drive system Bull gear, gear-pitch 5 mm |
