- Codice Macchina
- FL0864
- Manufacturer
- UTECO
- Modello
- DIAMOND HP 108
- Year
- 2011
- Numero di colori
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1550
- Larghezza stampa (mm)
- 1500
- Min print repeat (mm)
- 420
- Max print repeat (mm)
- 870
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Essiccazione
- 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers
- Videocamera
- YEAS GRAFYKONTROL WITH 100 % INSPECTION SYSTEM
- Guida film
- yes BST in and out
- Vyscosity control
- yes automatic
- Washing system
- yes automatic
- Sistema d'inchiostro
- closed chamber doctor blades ( 10+2 spares )
- Anilox
- 16 ceramic anilox sleeves
- Maniche stampa
- 60 + 10 carriers
- Ulteriori informazioni
- Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device Floorplan of the machine Width m. 7.60 Length m. 7.00pm Height m. 5.50
Codice Macchina | FL0864 |
Manufacturer | UTECO |
Modello | DIAMOND HP 108 |
Year | 2011 |
Numero di colori | 10 |
Print possibilityes | 10+0 |
Gearless | Yes |
Cambio a maniche rapido | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Larghezza nastro (mm) | 1550 |
Larghezza stampa (mm) | 1500 |
Min print repeat (mm) | 420 |
Max print repeat (mm) | 870 |
Unwinder type | Turret automatic |
Diametro massimo svolgitore (mm) | 1000 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 1000 |
Essiccazione | 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers |
Videocamera | YEAS GRAFYKONTROL WITH 100 % INSPECTION SYSTEM |
Guida film | yes BST in and out |
Vyscosity control | yes automatic |
Washing system | yes automatic |
Sistema d'inchiostro | closed chamber doctor blades ( 10+2 spares ) |
Anilox | 16 ceramic anilox sleeves |
Maniche stampa | 60 + 10 carriers |
Ulteriori informazioni | Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device Floorplan of the machine Width m. 7.60 Length m. 7.00pm Height m. 5.50 |
