- Codice Macchina
- FL794
- Manufacturer
- SCHIAVI
- Model
- SIRIO
- Year
- 1999
- Numero di colori
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Cambio a maniche rapido
- No
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1320
- Larghezza stampa (mm)
- 1270
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 750
- Unwinder type
- Turret Automatic
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 1000
- Essiccazione
- 2 zones - 4 fans - final tunnel-2 gas burners
- Videocamera
- yes BST
- Trattamento Corona
- yes MERO
- Guida film
- Yes in and out
- Sistema d'inchiostro
- Closed chamber doctor blades - 8 electrioc ink pumps
- Anilox
- 8 ceramic
- Maniche stampa
- Yes
- Ulteriori informazioni
- Motorized print station positioning- motorized remote controlled micrometric screws Motorized remote controlled longutudinal and side registers Chiller thermoregulator Tension range: 3-40 Kg Materials: PET from 12my, OPP from 15my, laminates up to 150 gr/m2, Alufoi+ paper electric hoists Min Machine speed from o to 300 Printing material LDPE, BOPP and other rigid films
| Codice Macchina | FL794 |
| Manufacturer | SCHIAVI |
| Model | SIRIO |
| Year | 1999 |
| Numero di colori | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Cambio a maniche rapido | No |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1320 |
| Larghezza stampa (mm) | 1270 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 750 |
| Unwinder type | Turret Automatic |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Essiccazione | 2 zones - 4 fans - final tunnel-2 gas burners |
| Videocamera | yes BST |
| Trattamento Corona | yes MERO |
| Guida film | Yes in and out |
| Sistema d'inchiostro | Closed chamber doctor blades - 8 electrioc ink pumps |
| Anilox | 8 ceramic |
| Maniche stampa | Yes |
| Ulteriori informazioni | Motorized print station positioning- motorized remote controlled micrometric screws Motorized remote controlled longutudinal and side registers Chiller thermoregulator Tension range: 3-40 Kg Materials: PET from 12my, OPP from 15my, laminates up to 150 gr/m2, Alufoi+ paper electric hoists Min Machine speed from o to 300 Printing material LDPE, BOPP and other rigid films |
