- Codice Macchina
- FL685
- Manufacturer
- FISCHER & KRECKE
- Modello
- 16S
- Year
- 2005
- Numero di colori
- 8
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Not specifed
- Larghezza nastro (mm)
- 1300
- Larghezza stampa (mm)
- 1250
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 800
- Diametro massimo svolgitore (mm)
- 1000
- Max reel diameter rewinder (mm)
- 1000
- Essiccazione
- Oil
- Videocamera
- BST Genius
- Guida film
- Fife OPG edge guide
- Vyscosity control
- Bloss Viscolour 1000 automatic
- Washing system
- F & K auto clean system
- Sistema d'inchiostro
- Solvent based
- Anilox
- approximately 10
- Maniche stampa
- 4 or 5 sets
- Ulteriori informazioni
- CI drum diameter: 1910mm Chrome nickel plated Mandrel diameter: 89.243mm Plate thickness: 1.7mm Winding system: flying splice Reel loading table at unwind In line slitting by razor blade centre slit only Web tension range: maximum 250N, minimum 10N Mechanical speed: 400m/min Materials: PE LDPE/HDPE, PP OPP/BOPP PET, PA approximately 10-120 microns Spreader roller before CI drum Auto fresh solvent intake and used solvent emptying Drying tunnel length: 5m Operator control OCS Carbon fibre mandrels x 3 sets
| Codice Macchina | FL685 |
| Manufacturer | FISCHER & KRECKE |
| Modello | 16S |
| Year | 2005 |
| Numero di colori | 8 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Not specifed |
| Larghezza nastro (mm) | 1300 |
| Larghezza stampa (mm) | 1250 |
| Min print repeat (mm) | 320 |
| Max print repeat (mm) | 800 |
| Diametro massimo svolgitore (mm) | 1000 |
| Max reel diameter rewinder (mm) | 1000 |
| Essiccazione | Oil |
| Videocamera | BST Genius |
| Guida film | Fife OPG edge guide |
| Vyscosity control | Bloss Viscolour 1000 automatic |
| Washing system | F & K auto clean system |
| Sistema d'inchiostro | Solvent based |
| Anilox | approximately 10 |
| Maniche stampa | 4 or 5 sets |
| Ulteriori informazioni | CI drum diameter: 1910mm Chrome nickel plated Mandrel diameter: 89.243mm Plate thickness: 1.7mm Winding system: flying splice Reel loading table at unwind In line slitting by razor blade centre slit only Web tension range: maximum 250N, minimum 10N Mechanical speed: 400m/min Materials: PE LDPE/HDPE, PP OPP/BOPP PET, PA approximately 10-120 microns Spreader roller before CI drum Auto fresh solvent intake and used solvent emptying Drying tunnel length: 5m Operator control OCS Carbon fibre mandrels x 3 sets |
