- Code Machine
- RO186
- Fabricant
- BOBST ROTOMEC
- Modello
- Rotopak 4000-2ES/1025/550/C
- Année
- 2002
- Number of colors
- 10
- Print possibilities
- 10 col print, 9 col + coating/ cold seal; Print + Lamination in line; print units 1,8,9,10 reversible, unit 9 with 2 lamination units, possibility of cold seal in register on unit 10
- Drive
- Electronic shaft
- Trolley system
- Yes
- Web width (mm)
- 1025
- Print width (mm)
- 1000
- Print repeat range (mm)
- 500-1000mm
- Drying specifications
- Pre treating unit 1,4m length, Unit 1 double hood 5m length 32 nozels 2 zones, unit2-7 single extended 3000mm 19 nozels, unit8 double extended hood 6000mm 38 nozels 2 zones, unit 9 double super extended 7000mm 46 nozels 2 zones, unit 10 double super extended 8000mm 52 nozels 2 zones
- Drying heat surce
- Thermal oil
- Unwinder type
- Turret two direction
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret two direction
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Eltromat Camera + 100PCT inspectin AVT Apollo
- Register controll
- Eltromat
- Vyscosity control
- Yes
- Corona treatment
- Albrandt
- Print cylinders
- No
- Note
- High performance rotogravure press. Mechanical Speed 550 m/min Secondary unwinder Turret max diam 1000mm Lamination unit AC driven. Roller water heated. Turning Bar Machine is currentlz dismantled
Code Machine | RO186 |
Fabricant | BOBST ROTOMEC |
Modello | Rotopak 4000-2ES/1025/550/C |
Année | 2002 |
Number of colors | 10 |
Print possibilities | 10 col print, 9 col + coating/ cold seal; Print + Lamination in line; print units 1,8,9,10 reversible, unit 9 with 2 lamination units, possibility of cold seal in register on unit 10 |
Drive | Electronic shaft |
Trolley system | Yes |
Web width (mm) | 1025 |
Print width (mm) | 1000 |
Print repeat range (mm) | 500-1000mm |
Drying specifications | Pre treating unit 1,4m length, Unit 1 double hood 5m length 32 nozels 2 zones, unit2-7 single extended 3000mm 19 nozels, unit8 double extended hood 6000mm 38 nozels 2 zones, unit 9 double super extended 7000mm 46 nozels 2 zones, unit 10 double super extended 8000mm 52 nozels 2 zones |
Drying heat surce | Thermal oil |
Unwinder type | Turret two direction |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret two direction |
Max reel diameter rewinder (mm) | 1000 |
Videocamera | Eltromat Camera + 100PCT inspectin AVT Apollo |
Register controll | Eltromat |
Vyscosity control | Yes |
Corona treatment | Albrandt |
Print cylinders | No |
Note | High performance rotogravure press. Mechanical Speed 550 m/min Secondary unwinder Turret max diam 1000mm Lamination unit AC driven. Roller water heated. Turning Bar Machine is currentlz dismantled |
