- Code Machine
- FL0867
- Fabricant
- COMEXI
- Modello
- FB2108
- Année
- 2006
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones - 4 fans - 4 mt tunnel - 2 gas burners
- Videocamera
- Yes AVT JUPITER , defect detection
- Web guides
- YES (camera type)
- Vyscosity control
- Yes
- Washing system
- Automatic
- Inking system
- Closed chamber doctor blades
- Anilox
- 16 ceramic anilox sleeves
- Print Sleeves
- totlly 70 ; 1x380 ,2x420 ,1x570 , 1x590 , 6x600 , 2x610 , 7x640 , 2x650 , 5x660 , 9x680 , 1x690 , 8x695 , 2x740 , 8x770 , 6x760 , 1x780 , 8x790
- Note
- mechanical speed 350 m/min
| Code Machine | FL0867 |
| Fabricant | COMEXI |
| Modello | FB2108 |
| Année | 2006 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones - 4 fans - 4 mt tunnel - 2 gas burners |
| Videocamera | Yes AVT JUPITER , defect detection |
| Web guides | YES (camera type) |
| Vyscosity control | Yes |
| Washing system | Automatic |
| Inking system | Closed chamber doctor blades |
| Anilox | 16 ceramic anilox sleeves |
| Print Sleeves | totlly 70 ; 1x380 ,2x420 ,1x570 , 1x590 , 6x600 , 2x610 , 7x640 , 2x650 , 5x660 , 9x680 , 1x690 , 8x695 , 2x740 , 8x770 , 6x760 , 1x780 , 8x790 |
| Note | mechanical speed 350 m/min |
