- Code Machine
- FL678
- Fabricant
- UTECO
- Modello
- EMERALD 825 UV -8+1
- Année
- 2000
- Number of colors
- 9
- Print possibilityes
- 8+1
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1250
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 750
- Unwinder type
- TWO POSITION
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- UV system - 7 UV lamps on CI drum , two UV lamps on chill roller and two UV lamps after downstream coating unit
- Videocamera
- yes
- Inking system
- Closed chamber doctor blades
- Note
- possibility to modify and add hot air driers for water based inks 7 drying boxes and two fans on CI section, 4,5 mt tunnel and two fans for second zone total cost of modification 120.000 Euuro final machine price 215.000 Euro
Code Machine | FL678 |
Fabricant | UTECO |
Modello | EMERALD 825 UV -8+1 |
Année | 2000 |
Number of colors | 9 |
Print possibilityes | 8+1 |
Gearless | No |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1250 |
Min print repeat (mm) | 320 |
Max print repeat (mm) | 750 |
Unwinder type | TWO POSITION |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret Automatic |
Max reel diameter rewinder (mm) | 800 |
Drying | UV system - 7 UV lamps on CI drum , two UV lamps on chill roller and two UV lamps after downstream coating unit |
Videocamera | yes |
Inking system | Closed chamber doctor blades |
Note | possibility to modify and add hot air driers for water based inks 7 drying boxes and two fans on CI section, 4,5 mt tunnel and two fans for second zone total cost of modification 120.000 Euuro final machine price 215.000 Euro |
