- Código Máquina
- LA163
- Constructor
- SCHIAVI
- Modello
- CL600
- Año
- 2009
- Application
- Duplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1350
- Materials
- Paper; Bopp; Bopp metallized; PP cast; PET; Cellophane; PE;Laminated materials; ALU; Rigid PVC; BOPA; PA
- Speed
- 300m/min
- First unwinder type
- SINGLE
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- SINGLE
- Max diameter reel unwinder
- 1000
- Rewinder type
- SINGLE
- Max diameter reel rewinder
- 1000
- Coating unit
- With interchangeable trolleys, suitable to utilize solventless, solvent and water based adhesives, cold seal.
- Drying
- Heating system to be defined (heat echanger not included).Horizontal drying tunnel, cascade type with 2 section. 3 fans; Final fan driven an AC motor. Thermoregulation through numeric machine control with feed-back by PT 100. Web introduction chain.
- pumping mixing unit
- Yes
- Corona treatment
- Yes
- Note
- Max/min web width 675 – 1300 mm.Max. coating width 1300mm. Unwinders :reels diameters 1000mm ; inside core diameter 76 or 152mm; max reel weight 1200kg; max. web tension adjustment range from 3 to 40kg; Rewinder: max reel diameter 1000mm ; inside core diameter 152mm; max. reel weight 1200kg; Max.web tension adjustment range from 4 to 40kg; Automatic web aligners, Schiavi make ; Laminating unit; Chill roll;Water temperature control unit;1 rotogravure trolley for quick change of the coating cylinder and of the whole coating group (for solvent and waterbased). 1 solventless trolley (coating trolley for solventless adhesives,4 roll system,3 rotating and 1 idle; 15 sleeves. Schleicher numeric control;
| Código Máquina | LA163 |
| Constructor | SCHIAVI |
| Modello | CL600 |
| Año | 2009 |
| Application | Duplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1350 |
| Materials | Paper; Bopp; Bopp metallized; PP cast; PET; Cellophane; PE;Laminated materials; ALU; Rigid PVC; BOPA; PA |
| Speed | 300m/min |
| First unwinder type | SINGLE |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | SINGLE |
| Max diameter reel unwinder | 1000 |
| Rewinder type | SINGLE |
| Max diameter reel rewinder | 1000 |
| Coating unit | With interchangeable trolleys, suitable to utilize solventless, solvent and water based adhesives, cold seal. |
| Drying | Heating system to be defined (heat echanger not included).Horizontal drying tunnel, cascade type with 2 section. 3 fans; Final fan driven an AC motor. Thermoregulation through numeric machine control with feed-back by PT 100. Web introduction chain. |
| pumping mixing unit | Yes |
| Corona treatment | Yes |
| Note | Max/min web width 675 – 1300 mm.Max. coating width 1300mm. Unwinders :reels diameters 1000mm ; inside core diameter 76 or 152mm; max reel weight 1200kg; max. web tension adjustment range from 3 to 40kg; Rewinder: max reel diameter 1000mm ; inside core diameter 152mm; max. reel weight 1200kg; Max.web tension adjustment range from 4 to 40kg; Automatic web aligners, Schiavi make ; Laminating unit; Chill roll;Water temperature control unit;1 rotogravure trolley for quick change of the coating cylinder and of the whole coating group (for solvent and waterbased). 1 solventless trolley (coating trolley for solventless adhesives,4 roll system,3 rotating and 1 idle; 15 sleeves. Schleicher numeric control; |
