Slitter rewinding machines are used to slit a single and wider reel of web into several narrower reels of materials.
Ask more informations
- Machine Code
- SR435
- Manufacturer
- KMEC
- Modello
- MECASLIT 135 RV
- Year
- 2000
- Working width (mm)
- 1350
- Materials
- Plastic, paper and laminates from 12 mx up to 600my
- Speed
- 400 m/min
- Unwinder type
- Shaftless with reel lifting from floor
- Max diameter reel unwinder
- 1000
- Rewinder type
- Double turret center driven
- Max diameter reel rewinder
- 650
- Rewinder description
- Double turret - expanding shafts
- Min slit width
- 75mm
- Knives
- Rotary knives Helios x 8
- Note
- Splicing table on unwinder max web tension 65KG
| Machine Code | SR435 |
| Manufacturer | KMEC |
| Modello | MECASLIT 135 RV |
| Year | 2000 |
| Working width (mm) | 1350 |
| Materials | Plastic, paper and laminates from 12 mx up to 600my |
| Speed | 400 m/min |
| Unwinder type | Shaftless with reel lifting from floor |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Double turret center driven |
| Max diameter reel rewinder | 650 |
| Rewinder description | Double turret - expanding shafts |
| Min slit width | 75mm |
| Knives | Rotary knives Helios x 8 |
| Note | Splicing table on unwinder max web tension 65KG |
