A duplex laminator will joins 2 layer of web, a triplex lamination machine will join 3 layers together in 1 pass. Coating machines are used to apply a layer of coated material onto a web (support).
Ask more informations
- Machine Code
- LA255
- Manufacturer
- CERUTTI
- Modello
- 940
- Year
- 1997
- Application
- Lamination + coating
- Type of lamination/coating
- SOLVENT / WATER BASED
- Working width (mm)
- 1050
- Materials
- Materials : paper from 30 up to 100 gr/sqm ; Alu( oil hard from 6.35 up to 15 my - for wet lamination only) ; Alufoil sof from 15 up to 50my
- First unwinder type
- Two direction flying splice - model CU 1 1 0; Web tension range: 5 to 50 daN. One platform for reel loading on the unwinder
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- One single axis unwinder model PB 38 for the unwinding of the unsupported foil. - Tension control via D C motor .One lever type loading system .
- Max diameter reel unwinder
- 1000
- Rewinder type
- Two direction flying splice ; type model CRI . Web tension range. 5 to 50 daN - Max. reel weight: 1 000 Kg. One outfeed pulling unit before the rewinder.Draw roller with rotary joint for cooling reasons.One platform for reel unloading on rewinder rnodel CRIIO
- Max diameter reel rewinder
- 1000
- Coating unit
- One coating unit model ES 940 M 2 driven by D.C. motor of the phase control ; with one gravure trolley; one wet laminating group built in coating unit (model Es 940 M2 driven by DC motor).; 1 semiflexo trolley for coating unit ES 940
- Second Coating unitr
- One printer coating unit model ES 940 E 2 reversible driven by DC motor with one gravure trolley
- Third Coating unit
- 1 semiflexo trolley for coating unit ES 940
- Coating rollers
- Sleeve type impression rollers .20 spare irnpression roller sleeves
- Note
- Fire fighting system One kiss coating group. One driven smoothing bar. Cooling units after coating units N. 1 and N. 2 driven by D.C. motors (No. 2 in total) plus pressure roller on the last cooling roller Coating unit No. I reversible One extra cooling roller for each coating unit (total 3) Three(3) web tension readout device consisting of load cells mounted on an idler roller with digital readout. Load cells roller positioned on main unwinder, secondary unwinder and on rewinder Digital display to show press speed One outfeed pulling unit One platform for reel loading on the unwinder model CUI; one lever loading system on the unwinder PB 38 One Cerutti Press SUpervision System One laminating machine main drive and control equipment Machie pre-wiring and saftey guards One set of standard accessories One heating/cooling pump group " stearling for laminating group Two impression pressure micrometric regulation device One peeling roller One spare expandable shaft for 76mm core diam and one spare expandable shaft for 152mm core diam
Machine Code | LA255 |
Manufacturer | CERUTTI |
Modello | 940 |
Year | 1997 |
Application | Lamination + coating |
Type of lamination/coating | SOLVENT / WATER BASED |
Working width (mm) | 1050 |
Materials | Materials : paper from 30 up to 100 gr/sqm ; Alu( oil hard from 6.35 up to 15 my - for wet lamination only) ; Alufoil sof from 15 up to 50my |
First unwinder type | Two direction flying splice - model CU 1 1 0; Web tension range: 5 to 50 daN. One platform for reel loading on the unwinder |
Max diameter reel unwinder | 1000 |
Secondary unwinder type | One single axis unwinder model PB 38 for the unwinding of the unsupported foil. - Tension control via D C motor .One lever type loading system . |
Max diameter reel unwinder | 1000 |
Rewinder type | Two direction flying splice ; type model CRI . Web tension range. 5 to 50 daN - Max. reel weight: 1 000 Kg. One outfeed pulling unit before the rewinder.Draw roller with rotary joint for cooling reasons.One platform for reel unloading on rewinder rnodel CRIIO |
Max diameter reel rewinder | 1000 |
Coating unit | One coating unit model ES 940 M 2 driven by D.C. motor of the phase control ; with one gravure trolley; one wet laminating group built in coating unit (model Es 940 M2 driven by DC motor).; 1 semiflexo trolley for coating unit ES 940 |
Second Coating unitr | One printer coating unit model ES 940 E 2 reversible driven by DC motor with one gravure trolley |
Third Coating unit | 1 semiflexo trolley for coating unit ES 940 |
Coating rollers | Sleeve type impression rollers .20 spare irnpression roller sleeves |
Note | Fire fighting system One kiss coating group. One driven smoothing bar. Cooling units after coating units N. 1 and N. 2 driven by D.C. motors (No. 2 in total) plus pressure roller on the last cooling roller Coating unit No. I reversible One extra cooling roller for each coating unit (total 3) Three(3) web tension readout device consisting of load cells mounted on an idler roller with digital readout. Load cells roller positioned on main unwinder, secondary unwinder and on rewinder Digital display to show press speed One outfeed pulling unit One platform for reel loading on the unwinder model CUI; one lever loading system on the unwinder PB 38 One Cerutti Press SUpervision System One laminating machine main drive and control equipment Machie pre-wiring and saftey guards One set of standard accessories One heating/cooling pump group " stearling for laminating group Two impression pressure micrometric regulation device One peeling roller One spare expandable shaft for 76mm core diam and one spare expandable shaft for 152mm core diam |
ROTOMEC duplex
-
Machine Code: LA426
-
Year: 1980
-
Working width (mm): 800
CML MIRACH
-
Machine Code: LA405
-
Year: 2002
-
Working width (mm): 1250
POLYTYPE POLYTYPE 522
-
Machine Code: LA348
-
Year: 1982
-
Working width (mm): 1040
NORDMECCANICA SUPER SIMPLEX
-
Machine Code: LA443
-
Year: 2015
-
Working width (mm): 1520
NORDMECCANICA SIMPLEX
-
