1 layers KIEFEL film blowing machine ** SOLD ** Ask more informations about a similar one
In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.
| Machine Code | EX626 |
| Manufacturer | KIEFEL |
| Year | 1991 |
| Number of layers | 1 |
| Material | LDPE, LLDPE, HDPE |
| Film Width (mm) | 1550 |
| Output (Kg/h) | 210 kg/h |
| Extruder 1 Layer ref: | A |
| Screw diam | 70 L/D24 |
| Description | gravimetric doser Macguire |
| Head description | IBC, fixed |
| Die diam (mm) | 175 mm |
| Bubble cage | yes layflat 1550mm |
| Panel for gussets | no |
| Take off unit | Rotating |
| Corona treatment | Martignoni - 2 sides corona, recently added |
| Additional information | Min film width - 600mm Output reel diam. 1000mm Min & max thickness: from 20 to 200 Speed: 100 m/min Controls and hdmi renovated Height 9,5m up to the ceiling 15m 1 heat exchanger and blower |
** SOLD **
