3 layers REIFENHAUSER Blown film extrusion line

In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.

Machine Code EX560
Manufacturer REIFENHAUSER
Year 2001
Number of layers 3
Material LDPE,LLDPE,MDPE,HDPE,PE
Film Width (mm) 1600
Output (Kg/h) 320 Kg/h
Extruder 1 Layer ref: A
Screw diam 60mm
Description L/D 30D .Gravimetric dosing unit
Extruder 2 Layer ref: B
Screw diam 80mm
Description L/D 30D .Gravimetric dosing unit
Extruder 3 Layer ref: C
Screw diam 60mm
Description L/D 30D .Gravimetric dosing unit
Head description IBC
Die diam (mm) 300 mm
Thickness controll system Yes, Plastcontrol
Take off unit Rotating
Corona treatment yes, AFS
Web guide yes
Rewinder max reel diameter 1000
Rewinder description Back to Back Reifenhauser UFA III3=E
Additional information Material thickness: 15-200my Inline Slitting Tower included
