1 layers REIFENHAUSER Blown film extrusion line ** SOLD ** Ask more informations about a similar one
In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.
| Machine Code | EX523 |
| Manufacturer | REIFENHAUSER |
| Year | 1990 |
| Number of layers | 1 |
| Material | HDPE, LLDPE, MDPE, LLDPE, mLLDPE, Bio Polymers. Thickness 6.5-100my |
| Film Width (mm) | 1200 |
| Output (Kg/h) | 200 |
| Screw diam | 70mm |
| Description | Reifenhauser Type Kompakt 3.35. year 1990. L/D30. Dosing unit Enginplast year 1994. 3 volumetric + 3 gravimetric components |
| Head description | No IBC system. Oscillating head type BK -F 0300-01-A3. year 1990.Cooling ring Reifenhauser year 1990. Dimensions 540-1350mm |
| Die diam (mm) | 175 |
| Take off unit | Fixed. Year 1990. Width 1200(1300)mm. |
| Corona treatment | F&B double year 1990 width 1700mm |
| Rewinder max reel diameter | 800MM |
| Rewinder description | Reifenhauser. Dimensions 1200(1280)mm |
| Additional information | Inline printing CMF Type 804 2+2 Year 1979. Width 1200mm Weight control Kunding year 1990 Width control Kunding year 1990.Dimensions 500-1700mm Microperforator F&b year 1987. Width 1600mm Min/max speed 15-150m/min |
** SOLD **
