3 layers DOLCI NEXTROM Cast film extrusion line

Cast film extrusion lines are commonly used to extrude plastic films especially for flexible packaging industry. / In a cast film extruder PE, PP or PA granulates (or other polymers) are melted inro an extruder and pushed through a flat extrusion die (T die), extruding a sheet of molten polymer onto a cooled roller (chill roll).

Machine Code CA156
Manufacturer DOLCI
Model NEXTROM
Year 1999
Number of layers 3
Film structure ABC
Material STRETCH FILM, LLDPE
Film width (mm) 2000
Speed (m/min) 350 m/min
Output (Kg/h) 1100 kg/h
Extruder 1 Layer ref: A
Screw diam 90 mm
Extruder 2 Layer ref: B
Screw diam 180 mm
Extruder 3 Layer ref: C
Screw diam 120 mm
Thickness controll system Beta Ray Scanner
Rewinder description New Rewinder by ADTECH Provera for hand and automatic rolls
Additional information Gravimetric Dosing Units Stretch film roll type - hand Automatic packaging of rolls Power supply - 380V/50Hz threephase + E+N Edge recovering system Stretch film rolls width (mm) 450/500 Installed power (Kw) - 1400 Air pressure min (bar) - 6
