DCM HLS Rotogravure printing machine 8 colors

Rotogravure printing machines (roto or gravure for short) perform a type of intaglio printing process, which involves engraving the image onto a cylinder which become the image carrier. Every printing job will require its dedicated set of engraved cylinders.

Machine Code	RO231
Manufacturer	DCM
Model	HLS
Year	2000
Number of colors	8
Overhaul/renovation	up to 2021 several upgrades
Drive	Electronic shaft
Trolley system	Yes
Web width (mm)	710
Print width (mm)	700
Print repeat range (mm)	320-560 mm
Drying specifications	Thermo oil
Unwinder type	2 turret unwinders non stop
Max reel diameter unwinder (mm)	800
Rewinder type	2 turret unwinders non stop
Max reel diameter rewinder (mm)	800
Videocamera	Camera BST Nyquist Tube scan 100% inspection + 2xBST Handyscan, digital camera 4k with defect control
Vyscosity control	automatic, Inkspec
Additional information	Machine is tandem, means it can work 2 different jobs at the same time (e.g 1 job 4 colour+ second job 4 color or e.g 1 job 2 colour and second job 6 colours UNIT: 4-5-6-7-8 reversible Substrate Materials: soft and hard aluminium foil, laminate, film and paper all units with double drying hoods Web guide ekt 1000 Materials: soft aluminium and hard, laminates, film, paper (depending on gramages) Mandrels 70 and 152 mm Shaftless machine: automatic cylinder clamping Max speed: 200 m/min
