BOBST ROTOMEC ROTOPACK 4004 ES Rotogravure printing machine 8 colors

Gravure presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
Machine Code
RO179
Manufacturer
BOBST ROTOMEC
Modello
ROTOPACK 4004 ES
Year
2004
Number of colors
8
Print possibilities
8+0 print plus coating. Unit 8 reversible. Turning bar on unit 8
Overhaul/renovation
2007
Drive
Electronic shaft
Trolley system
Yes
Web width (mm)
1020
Print width (mm)
1000
Print repeat range (mm)
350-800 mm
Drying specifications
8 INDEPENDENT drying section 8 blowing fans , one general exhaust oil heated, unit 1 double, unit 2-7 single, unit 8 double extended
Drying heat surce
thermo oil
Unwinder type
Turret shaftless
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret shaftless
Max reel diameter rewinder (mm)
1000
Videocamera
video camera bst
Register controll
yes Eltromat
Vyscosity control
No
Corona treatment
Yes , shermann
Print cylinders
sleeve type gravure
Note
Plc siemens s7 Gearless electronic shaft siemens drives and motors 2x web guide 16 trolleys Lel control system Speed 350 mpm
Machine Code RO179
Manufacturer BOBST ROTOMEC
Modello ROTOPACK 4004 ES
Year 2004
Number of colors 8
Print possibilities 8+0 print plus coating. Unit 8 reversible. Turning bar on unit 8
Overhaul/renovation 2007
Drive Electronic shaft
Trolley system Yes
Web width (mm) 1020
Print width (mm) 1000
Print repeat range (mm) 350-800 mm
Drying specifications 8 INDEPENDENT drying section 8 blowing fans , one general exhaust oil heated, unit 1 double, unit 2-7 single, unit 8 double extended
Drying heat surce thermo oil
Unwinder type Turret shaftless
Max reel diameter unwinder (mm) 1000
Rewinder type Turret shaftless
Max reel diameter rewinder (mm) 1000
Videocamera video camera bst
Register controll yes Eltromat
Vyscosity control No
Corona treatment Yes , shermann
Print cylinders sleeve type gravure
Note Plc siemens s7 Gearless electronic shaft siemens drives and motors 2x web guide 16 trolleys Lel control system Speed 350 mpm
