ROTOMEC BOBST 4003 MP 1350 Gravure printing machine 9 colors ** SOLD ** Ask more informations about a similar one

Gravure presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code RO148
Manufacturer ROTOMEC BOBST
Model 4003 MP 1350
Year 2011
Number of colors 9
Print possibilities 8+1, 9+0
Drive Electronic shaft
Trolley system Yes
Web width (mm) 1350
Print width (mm) 1325
Print repeat range (mm) 450-920 mm
Drying specifications units 2 to 7 , 1 blowing fan each unit ( totally 6 ) , single drying hood 2, 5 mt , and one main common exhaust fan ; for units 1, 8 and 9 double drying hood 2 x 2,,5 mt , 1 blowing and 1 exhaust fan each one of the three units . Automatic air recirculation unit with LEL control by Rotomec Zellweger for all units -12 control zones
Drying heat surce Thermo oil heating system one for each zone totally 12 with independent preset and control
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 1000
Videocamera yes
Register control Automatic long and side register cobtrol BOBST REGISTRON S 5100 E4 + automatic fast pre register system T.A.P.S.
Vyscosity control 8 automatic Rotomec New Celio mod 1600 RT
Corona treatment YES by MERO
Print cylinders 800 already engraved
Additional information 16 trolleys Electrostatic assistance system and discharge by ACE Heting preconditioning unit Totally automatic pre register system ( TAPS ) Fire detection and protection system on all units 9 antistatic bars ACE 18 trolleys

** SOLD **
