FISCHER & KRECKE 16S-8 (GEARLESS) flexographic printing machine 8 colors

** SOLD **

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
about a similar one
Machine Code
FL542
Manufacturer
FISCHER & KRECKE
Model
16S-8 (GEARLESS)
Year
2004
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1320
Print width (mm)
1270
Min print repeat (mm)
380
Max print repeat (mm)
800
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
1000
Drying
2 x diathermic oil heat exchangers. 2 zone drying (print unit and tunnel) 2 x inlet fans; 2 x outlet fans; 5m long tunnel
Videocamera
BST Genious
Corona treatment
Motorized type, Make Albrandt
Web guides
yes
Vyscosity control
Included
Washing system
Not included
Inking system
8 chamber doctor blades
Anilox
340 - 5,4 cm3/m2 - 8 pieces Apex ; 200 - 8,0 cm3/m2 - 2 pieces Apex ; 160 - 8.6 cm3/m2 - 2 pieces Apex; 140 - 10,0 cm3/m2 - 2 pieces Apex
Print Sleeves
24 sleeves (8 x 3) without carbon adaptors
Additional information
Mechanical speed 450 m/min, Print unit motors and drives Indramat, Plate thickness - 1,14 mm.
Machine Code FL542
Manufacturer FISCHER & KRECKE
Model 16S-8 (GEARLESS)
Year 2004
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1320
Print width (mm) 1270
Min print repeat (mm) 380
Max print repeat (mm) 800
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Drying 2 x diathermic oil heat exchangers. 2 zone drying (print unit and tunnel) 2 x inlet fans; 2 x outlet fans; 5m long tunnel
Videocamera BST Genious
Corona treatment Motorized type, Make Albrandt
Web guides yes
Vyscosity control Included
Washing system Not included
Inking system 8 chamber doctor blades
Anilox 340 - 5,4 cm3/m2 - 8 pieces Apex ; 200 - 8,0 cm3/m2 - 2 pieces Apex ; 160 - 8.6 cm3/m2 - 2 pieces Apex; 140 - 10,0 cm3/m2 - 2 pieces Apex
Print Sleeves 24 sleeves (8 x 3) without carbon adaptors
Additional information Mechanical speed 450 m/min, Print unit motors and drives Indramat, Plate thickness - 1,14 mm.
