8 colors FISCHER & KRECKE 10 DF Flexo central drum printing press

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Machine Code FL620
Manufacturer FISCHER & KRECKE
Model 10 DF
Year 1996
Number of colors 8
Print possibilities 8+0
Gearless No
Fast sleeve change No
Web width (mm) 830
Print width (mm) 815
Max reel diameter unwinder (mm) 800
Rewinder type TURRET
Drying 2 Zones -4 fabs- Thermo oil heat exchangers , recirculation system with LEL control
Videocamera YES Eltromat video4
Corona treatment YES
Web guides YES Fife in and out
Inking system Closed Chamber Doctor blades
Anilox 1 x 360 l/cm–vol.5,5 ; 4x315 l/cm-vol 4,5 ; 2x315-vol.6,5 ; 2x255–vol.8 ; 2x220–vol.6,5 ; 1x200-vol.10 ; 1x160-vol.7,8 ; 1x160-vol.12,1 ; 1x160-vol.12,3
Print cylinders 8 x 370 mm, 8 x 420 , 8 x 440 , 8 x 450 , 8 x 580
Additional information Four motor type print station position system Motorized longitudinal and side registers remote controlled
