UTECO EMERALD 825 -- 8+1 Flexo central drum printing press 9 colors

** SOLD **

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
about a similar one
Machine Code
FL570
Manufacturer
UTECO
Modello
EMERALD 825 -- 8+1
Year
2001
Number of colors
9
Print possibilityes
8+0, 8+1 front, 8+1 back
Gearless
No
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1050
Print width (mm)
1000
Min print repeat (mm)
280
Max print repeat (mm)
780
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
1000
Drying
2 zone,4 fans, tunnel 4mt , thermo oil heaters
Videocamera
BST Pro Scan
Web guides
yes, in and out
Washing system
no
Inking system
closed chamber doctor blades
Anilox
15 ceramic anilox sleeves
Print Sleeves
15 sets repeats 29, 30,31, 32,34,37,40,43,46,48,50,52,54, 56, 57,5 cm. Double set of gears for each set of sleeve in order to use 1.14 or 2.54 mm plate thickeness, pitch 5 mm
Note
Complete Computer supervision. Automatic pre register Motorized remote controlled longitudinal and side register Print / Coating stack unit in line, front or back side with register control Zelo
Machine Code FL570
Manufacturer UTECO
Modello EMERALD 825 -- 8+1
Year 2001
Number of colors 9
Print possibilityes 8+0, 8+1 front, 8+1 back
Gearless No
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1050
Print width (mm) 1000
Min print repeat (mm) 280
Max print repeat (mm) 780
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Drying 2 zone,4 fans, tunnel 4mt , thermo oil heaters
Videocamera BST Pro Scan
Web guides yes, in and out
Washing system no
Inking system closed chamber doctor blades
Anilox 15 ceramic anilox sleeves
Print Sleeves 15 sets repeats 29, 30,31, 32,34,37,40,43,46,48,50,52,54, 56, 57,5 cm. Double set of gears for each set of sleeve in order to use 1.14 or 2.54 mm plate thickeness, pitch 5 mm
Note Complete Computer supervision. Automatic pre register Motorized remote controlled longitudinal and side register Print / Coating stack unit in line, front or back side with register control Zelo
** SOLD **
