6 colors OFEM COLUMBUS 7 flexo press

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Machine Code FL626
Manufacturer OFEM
Model COLUMBUS 7
Year 1996
Number of colors 6
Print possibilities 6+0
Gearless No
Fast sleeve change No
Web width (mm) 1270
Print width (mm) 1200
Max reel diameter unwinder (mm) 800
Rewinder type Double axis turret flying splice
Drying Drying system Hot air .Heating source Gas burner
Videocamera 1 video inspection system FIFE.
Web guides 1 before print and 1 before rewind
Inking system Solvent based .4 Printing units (stations 2-3-4-5) equipped with enclosed doctor blade chambers with ceramic anilox rollers; 2 Printing units (stations 1 and 6) equipped with fountain rubber roller (machine prepared for application of enclosed doctor blades as the other units)
Anilox 6 anilox roller ceramic coated and laser engraved as reported below: 1 roller engraved to 8 lines/cm.4 rollers engraved to 120 lines/cm.1 roller engraved to 260 lines/cm.
Print cylinders Plate rollers as reported below: 6 repeat length 400 mm; 450;500;540;550;600;700 ;1 rubber covered for continuos print width 500 mm.1 rubber covered for continuos print width 1000 mm. 6 repeat length 410 mm. 420;430;470;490;590mm
Additional information Length registers motorized remote controlled Manual side registers Decks’ positioning system Automatic with microprocessor, 1 motor each deck Manual Locking system of the printing units Hoisting systems:Double electric hoist for printing rollers handling Razor blade slitting unit with trim aspirator.
