UTECO EMERALD 825 synchro gearless Flexo printer 8 colors ** SOLD ** Ask more informations about a similar one

Flexo CI presses use a central drum which is common to all colours as counter impression roll.

Machine Code FL480
Manufacturer UTECO
Model EMERALD 825 synchro gearless
Year 2002
Number of colors 8
Print possibilities 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 330
Max print repeat (mm) 700
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 1000
Drying 2 zones 4 fans - thermo oil heat exchangers
Videocamera BST PROSCAN
Web guides BST Kamberoller
Washing system YES
Inking system 8 closed chamber doctor based. Solvent based. 8 inking pumps. 8 ink trays
Anilox 1X 320 L/cm vol 6cm3/M2 , 2x340 vol 5.5; 1x360 vol 4.8; 2x60 vol 20;, 2x80 vol 16,1; 2x100 vol16; ,2x118 vol18; , 1x260 vol 5.2; 2x220L/cm vol 8.5cm3/M2;
Print Sleeves 8X350mm , 7X 400 , 6 X 420 , 8X450 , 8X500 , 7X550 , 8X600 , 8X650mm
Additional information Videocamera replaced in 2014 Slitting device at rewinder Rotary knives helios type with trim exhaust . Chiller ; Thermoregulation system . Motorized registers .Trimming system Speed 300m/min Materials:paper , LDPE, HDPE, BOPP, POLIESTER Tension :3,5 to 50 kg Thickness clichè 1,14mm

** SOLD **
