8 colors UTECO EMERALD 825 synchro gearless flexographic printing machine ** SOLD ** Ask more informations about a similar one
Flexo CI presses use a central drum which is common to all colours as counter impression roll.
| Machine Code | FL480 |
| Manufacturer | UTECO |
| Model | EMERALD 825 synchro gearless |
| Year | 2002 |
| Number of colors | 8 |
| Print possibilities | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Drying | 2 zones 4 fans - thermo oil heat exchangers |
| Videocamera | BST PROSCAN |
| Web guides | BST Kamberoller |
| Inking system | 8 closed chamber doctor based. Solvent based. 8 inking pumps. 8 ink trays |
| Anilox | 1X 320 L/cm vol 6cm3/M2 , 2x340 vol 5.5; 1x360 vol 4.8; 2x60 vol 20;, 2x80 vol 16,1; 2x100 vol16; ,2x118 vol18; , 1x260 vol 5.2; 2x220L/cm vol 8.5cm3/M2; |
| Print Sleeves | 8X350mm , 7X 400 , 6 X 420 , 8X450 , 8X500 , 7X550 , 8X600 , 8X650mm |
| Additional information | Videocamera replaced in 2014 Slitting device at rewinder Rotary knives helios type with trim exhaust . Chiller ; Thermoregulation system . Motorized registers .Trimming system Speed 300m/min Materials:paper , LDPE, HDPE, BOPP, POLIESTER Tension :3,5 to 50 kg Thickness clichè 1,14mm |
** SOLD **
