6 colors OFEM JULIETTE flexo press

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Machine Code FL071
Manufacturer OFEM
Model JULIETTE
Year 2000
Number of colors 6
Print possibilities 6+0
Gearless No
Fast sleeve change Yes
Web width (mm) 650
Print width (mm) 600
Max reel diameter unwinder (mm) 1250
Rewinder type Single position
Drying 2 zones 4 fans - Gas burner
Videocamera yes BST Super Handy Scan
Inking system Enclosed doctor blade chambers with ceramic anilox rollers
Anilox Anilox as follows: 6 x 180L x g. 7,5 2 x 150L x g. 8,2 3 x 110L x g. 13 2 x 80L x g. 16 1 x 60L x g. 20.8 2 x 140L x g. 9.5 / 10 2 x 255 x g 5/5.5
Print Sleeves Printing sleeves brand EVERGREEN with gears as follows: 12x25cm,12x26, 12x27, 12x28, 12x29, 24x30, 18x31, 18x32, 18x33, 18x34, 12x35, 12x36, 18x37, 12x38, 12x39, 12x40, 12x44, 12x45, 12x48 cm. plus 6 carriers. Sleeves for full solid printing, range 507 mm 2x300, range 647mm 1x300, range 647mm 1x370, range 345 mm 1x350mm.
Print cylinders Plate cylinder gears: 8x25cm, 8x26cm, 8x27cm, 8x28cm, 6x29cm, 6x30cm, 6x31cm, 6x32cm, 6x33cm, 6x34cm, 6x35cm, 6x36cm, 6x37cm, 6x38cm, 6x39cm, 6x40cm, 6x44cm, 6x45cm, 6x48cm
Additional information Material: paper 40 - 140 gsm Type of inks: flexographic water based, converted to use of solvent based as well Turner bars system 6+6 recently installed
