WINDMÖLLER & HÖLSCHER ASTRAFLEX flexographic printing machine 8 colors
Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.
| Machine Code | FL918 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Model | ASTRAFLEX |
| Year | 2000 |
| Number of colors | 8 |
| Print possibilities | 8+0 |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 370 |
| Max print repeat (mm) | 1200 |
| Unwinder type | Shaftless turret automatic Web tension range 2,5 - 35 Kg |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Shaftless turret automatic Web tension range ,5 - 45 kg |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones with 4 fans final drying tunnel , thermo oil heat exchangers |
| Videocamera | YES , AVT |
| Web guides | Yes in and out |
| Vyscosity control | 8 viscosity control BLOSS |
| Inking system | Closed chamber doctor blades |
| Anilox | 36 ceramic anilox rollers as follwos 2 x 460 l/cm- vol 5,5 ; 4 x 400 l/cm-vol.6 ; 4 x 300 l/cm- vol 7,5 ; 6 x 250 l/cm - vol 9,5 ; 4 x 260 l/cm -vol.4 ; 3 x 220 l/cm -vol 12 ; 3 x 220 l/cm- vol.6 ; 3 x 160 l/cm vol 13 , 3 x 110 l/cm -vol. 15 ; 1x 100 l/cm -vol 17,6 ; 1 x 80 l/cm vol 20 |
| Print cylinders | 192 air cyilinders repeat 370 - 400 - 450 - 490- 500 - 550 - 600 - 650- 700 - 750 - 800 - 850 - 900 - 950 suitable fpor repeat up to 1020 mm |
| Additional information | SLEEVE CHANGE ON PRINT CYLINDERS PORTALIFT FOR CYILNDERS AND ANILOX CHANGE Computer control WH PROCONTROL |
