SCHIAVI BOBST ALPHA flexo printing machine 8 colors

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL859
Manufacturer
SCHIAVI BOBST
Modello
ALPHA
Year
2004
Number of colors
8
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Not specifed
Computer supervision
Yes
Web width (mm)
850
Print width (mm)
830
Min print repeat (mm)
290
Max print repeat (mm)
600
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
800
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
800
Drying
Gas
Videocamera
BST
Web guides
Yes, OPG
Vyscosity control
Yes, NEW CELIO
Washing system
Yes
Anilox
2 x160 l/cm, 2x 280 l/cm, 1x60 l/cm, 1x80 l/cm, 1x100 l/cm, 1x100 l/cm
Print Sleeves
8x270, 8x280, 8x290, 16x300, 8x310, 8x320, 16x330, 8x340, 8x350, 16x360, 8x370, 16x380, 16x390, 16x400, 16x410, 16x420, 16x425, 8x430, 16x440, 8x450, 8x460, 16x470, 16x480, 8x490, 4x495, 8x500, 8x510, 16x520, 16x530, 16x540, 16x550, 8x560, 16x580, 8x600
Machine Code FL859
Manufacturer SCHIAVI BOBST
Modello ALPHA
Year 2004
Number of colors 8
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Not specifed
Computer supervision Yes
Web width (mm) 850
Print width (mm) 830
Min print repeat (mm) 290
Max print repeat (mm) 600
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 800
Drying Gas
Videocamera BST
Web guides Yes, OPG
Vyscosity control Yes, NEW CELIO
Washing system Yes
Anilox 2 x160 l/cm, 2x 280 l/cm, 1x60 l/cm, 1x80 l/cm, 1x100 l/cm, 1x100 l/cm
Print Sleeves 8x270, 8x280, 8x290, 16x300, 8x310, 8x320, 16x330, 8x340, 8x350, 16x360, 8x370, 16x380, 16x390, 16x400, 16x410, 16x420, 16x425, 8x430, 16x440, 8x450, 8x460, 16x470, 16x480, 8x490, 4x495, 8x500, 8x510, 16x520, 16x530, 16x540, 16x550, 8x560, 16x580, 8x600
