WINDMOLLER & HOLCHER PRIMAFLEX CS Flexo printer 8 colors

** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Ask more informations
about a similar one
Machine Code
FL833
Manufacturer
WINDMOLLER & HOLCHER
Model
PRIMAFLEX CS
Year
2005
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
850
Print width (mm)
820
Min print repeat (mm)
250
Max print repeat (mm)
800
Unwinder type
Turret Automatic non-stop
Max reel diameter unwinder (mm)
800
Rewinder type
Turret Automatic non-stop
Max reel diameter rewinder (mm)
800
Drying
Electric - Drying between colors and bridge dryer system
Videocamera
BST
Corona treatment
Corona AFS Treatment
Web guides
Before printing and after rewinding BST
Washing system
yes
Inking system
Water /solvent . Doctor Blade Chamber
Anilox
Approx. 16
Print Sleeves
Approx. 150
Additional information
Material to be printed PAPER / PE / LDPE / HDPE / PA / PP / OPP / BOPP / PET Length register : through gearless Side register : electric - Motorized 8 - Pneumatic PUMPS Length cutting with circular knifes
Machine Code FL833
Manufacturer WINDMOLLER & HOLCHER
Model PRIMAFLEX CS
Year 2005
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 850
Print width (mm) 820
Min print repeat (mm) 250
Max print repeat (mm) 800
Unwinder type Turret Automatic non-stop
Max reel diameter unwinder (mm) 800
Rewinder type Turret Automatic non-stop
Max reel diameter rewinder (mm) 800
Drying Electric - Drying between colors and bridge dryer system
Videocamera BST
Corona treatment Corona AFS Treatment
Web guides Before printing and after rewinding BST
Washing system yes
Inking system Water /solvent . Doctor Blade Chamber
Anilox Approx. 16
Print Sleeves Approx. 150
Additional information Material to be printed PAPER / PE / LDPE / HDPE / PA / PP / OPP / BOPP / PET Length register : through gearless Side register : electric - Motorized 8 - Pneumatic PUMPS Length cutting with circular knifes
** SOLD **
