** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL823
- Manufacturer
- SCHIAVI
- Modello
- SIGMA
- Year
- 2003
- Number of colors
- 8
- Print possibilityes
- 8+0
- Overhaul/renovation
- 2012 - New inking system
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 750
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones 4 fans - Thermo oil heat exchangers - Automatic recirculation system with LEL controls
- Videocamera
- YES AVT
- Corona treatment
- Yes driven by Mero
- Web guides
- BST EKR 1000 in and out
- Vyscosity control
- yes
- Washing system
- yes by TRESU
- Inking system
- Closed chmaber doctor blades TRESU
- Anilox
- 33 CERAMIC ANILOX SLEEVS , from 60 l/cm to 460 l/cm
- Print Sleeves
- 320 print sleeves, 4 sets of carriers
- Note
- New complete inking system complete with ink tanks and pneumatic pumps, solvent automatic mixing system for 3 different solvents, new closed chamber doctor blades TRESU, Autowash up system , viscosity control system . double set of closed chamber doctor bòlades and ink tanks covers
Machine Code | FL823 |
Manufacturer | SCHIAVI |
Modello | SIGMA |
Year | 2003 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Overhaul/renovation | 2012 - New inking system |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1220 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 750 |
Unwinder type | Turret Automatic |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret Automatic |
Max reel diameter rewinder (mm) | 800 |
Drying | 2 zones 4 fans - Thermo oil heat exchangers - Automatic recirculation system with LEL controls |
Videocamera | YES AVT |
Corona treatment | Yes driven by Mero |
Web guides | BST EKR 1000 in and out |
Vyscosity control | yes |
Washing system | yes by TRESU |
Inking system | Closed chmaber doctor blades TRESU |
Anilox | 33 CERAMIC ANILOX SLEEVS , from 60 l/cm to 460 l/cm |
Print Sleeves | 320 print sleeves, 4 sets of carriers |
Note | New complete inking system complete with ink tanks and pneumatic pumps, solvent automatic mixing system for 3 different solvents, new closed chamber doctor blades TRESU, Autowash up system , viscosity control system . double set of closed chamber doctor bòlades and ink tanks covers |
