UTECO EMERALD 107 flexo press 10 colors

** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Ask more informations
about a similar one
Machine Code
FL803
Manufacturer
UTECO
Modello
EMERALD 107
Year
2003
Number of colors
10
Print possibilityes
10+Solventless lamination
Overhaul/renovation
Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1250
Print width (mm)
1200
Min print repeat (mm)
350
Max print repeat (mm)
800
Unwinder type
Turret automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret automatic
Max reel diameter rewinder (mm)
800
Drying
2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
Videocamera
yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
Corona treatment
yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
Web guides
yes
Vyscosity control
yes new Gama 2017
Washing system
yes
Inking system
doctor blades - new 2016
Anilox
40 ceramic anilox sleeves
Print Sleeves
800 totally
Note
10 color CI with solventless lamination in line
Machine Code FL803
Manufacturer UTECO
Modello EMERALD 107
Year 2003
Number of colors 10
Print possibilityes 10+Solventless lamination
Overhaul/renovation Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 350
Max print repeat (mm) 800
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
Videocamera yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
Corona treatment yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
Web guides yes
Vyscosity control yes new Gama 2017
Washing system yes
Inking system doctor blades - new 2016
Anilox 40 ceramic anilox sleeves
Print Sleeves 800 totally
Note 10 color CI with solventless lamination in line
