UTECO ONYX 808 Flexo central drum printing press 8 colors

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code FL863
Manufacturer UTECO
Model ONYX 808
Year 2006
Number of colors 8
Print possibilities 8+0 , 4+4
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1550
Print width (mm) 1500
Min print repeat (mm) 380
Max print repeat (mm) 800
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying 2 zones , 4 fans , 4 mt finak tunnel , thermo oil heaters
Videocamera Yes BST double camera front and back inspection
Web guides yes in and out
Vyscosity control yes automatic
Washing system yes automatic
Inking system Closed chamber doctor blades 8 + 6 spares
Anilox totally 28 ceramic anilox sleeves
Print Sleeves 220 print sleeves + 1 set of carriers
Additional information Turning bar full width for 4+ 4 front and back printing complete with additional driers and register control
