9 colors UTECO EMERALD 825 GL 8+1 flexo press ** SOLD ** Ask more informations about a similar one

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code FL796
Manufacturer UTECO
Model EMERALD 825 GL 8+1
Year 2001
Number of colors 9
Print possibilities 8 (front) flexo + 1 (front) roto ; 1 (front) flexo + 1(back) roto
Gearless Yes
Fast sleeve change Yes
Web width (mm) 1250
Print width (mm) 1200
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Drying Thermal oil
Videocamera No
Corona treatment Vetapone
Web guides FIFE
Inking system 8 doctor blades ; 8 ink pumps
Anilox 1x4.5\400 ;3x5.5\340,6x5.5\300,1x4.7\315,1x4.4\400,1x7\280,1x5\280,1x5\290 ,1x7.5\160,1x8.5\110,1x7\160,2x12\160,3x12\120,1x10\140, 1x10\80 ,1x12\80, 1x20\80
Print Sleeves 8x350,8x360,8x370,8x374,8x380,8x390,13x400,8x410,8x415,8x420,13x430 ,8x440,18x450,7x460,8x465,8x470,13x480,8x490,9x510,8x520,7x521,8x525, 8x530,11x540,8v550,8x566,8x570,8x582,8x590,8x610,8x630,8x650,8x660
Additional information Number of colors:8 flexo + 1 gravure. Thickness of printing plates and of adhesive for the plate:1.14 + 0.55 Control tension type:Dancer Speed 300m/min Materials: Bopp/OPP/PP 15-50my; PET 15-25my; LDPE 40-150my;paper 30-120 gr/m2; Alu foil 29-40my Thermostat for CI 19m lenght - 5.23 Height Installed power 220 kw Preregister Length register controlled by PLC Pre- register system Refrigerating unit for cooling cylinder Driven Infeed calender with tension control

** SOLD **
