8 colors UTECO AMBER 808 Flexo printer

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Machine Code	FL047
Manufacturer	UTECO
Model	AMBER 808
Year	1995
Number of colors	8
Gearless	No
Fast sleeve change	No
Web width (mm)	1550
Print width (mm)	1500
Max reel diameter unwinder (mm)	1000
Rewinder type	Turret automatic
Drying	2 zones 4 fans -4 mt tunnel- steam heat exchangers
Videocamera	included
Corona treatment	FERRARINI BENELLI suitable for metallized
Web guides	FIFE in and out
Anilox	Ceramics anilox : 17 ( 1x 500, 2x300, 6x260, 2x200, 2x120, 1x110, 2x100, 1x80 L/cm),
Print Sleeves	32
Print cylinders	Cylinders : 136 8x320,330,340,360,390,410,440,470,490,520,540,560,580,590,610,650,690mm
Additional information	Gear pitch 5mm , Material : all plastic films and laminated; Motorized print station positioning with repeat preset, preregister, motorized long. registers , Driven Infeed roller with automatic web tension control ; Slitter in line Helios Banana roller.
