SCHIAVI EF 5040 (GEARLESS) flexo press 10 colors ** SOLD ** Ask more informations about a similar one
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Machine Code | FL418 |
Manufacturer | SCHIAVI |
Model | EF 5040 (GEARLESS) |
Year | 2006 |
Number of colors | 10 |
Overhaul/renovation | yes 2016 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1320 |
Print width (mm) | 1270 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 1020 |
Unwinder type | Turret unwinder |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret rewinder |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 gas burners, 2 zones 4 fans 4,75 tunnel, Automatic recirculation system with LEL control for each zone |
Videocamera | Deco System with Auto Register control and Quality control |
Corona treatment | yes |
Web guides | Yes in and out |
Vyscosity control | Yes |
Washing system | Yes |
Inking system | Closed chamber doctor blades |
Anilox | 32 ceramic anilox sleeves. 6 x 340 l/cm , 5x 280 l/cm; 1x 260 l/cm; 4x 220 l/cm; 3x 200 l/cm; 5x 180 l/cm; 1x 160 l/cm; 4x 120 l/cm |
Print Sleeves | 300 as follwos 10 sleevs for each repeat 400mm, 410 , 420, 430 , 440 , 450 , 460, 480 , 500 , 510, 520 , 530 , 540 , 550,560, 570, 580, 600, 620, 640, 660, 670, 680, 720, 740, 760, 780, 850, 890 |
Print cylinders | 2 set of carriers |
Additional information | Sleeve change for print sleeves and anilox rollers;Fast job system with "Random Deck change" ; Automatic register Control ; Automatic print pressure control ; 2 set of carbonfiber carriers (1x 10) ; |
** SOLD **
