8 colors UTECO ONYX 810 GL flexo printing machine ** SOLD ** Ask more informations about a similar one

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Machine Code FL764
Manufacturer UTECO
Model ONYX 810 GL
Year 2006
Number of colors 8
Print possibilities 8+0
Overhaul/renovation 2011 - Grafikontrol camera with clik&drag; 2013, new chambers and new washing system
Gearless Yes
Fast sleeve change Yes
Web width (mm) 1250
Print width (mm) 1200
Max reel diameter unwinder (mm) 800
Rewinder type AUTOMATIC TURRET
Drying 2 zones ; 2 gas burners; 4 fans; Extended drying tunnel 6 mt long ; automatic air recirculation system with LEL control by Heck
Videocamera AUTOMATIC PRINT SETTING CLICK&DRAG
Web guides 2 X EDGE GUIDE CONTROL
Inking system CLOSED CHAMBER DOCTOR BLADE NEW SYSTEM 2013 - PNEUMATIC INK PUMPS
Anilox 17 ceramic anilox sleeves 6x340 l/cm-vol.1,24 ; 2x340 l/cm-vol.1,3 ; 7x250 l/cm-vol.1,74 ;
Print Sleeves 199 as follows : 16 x400 mm ; 8x410mm ; 8x420mm ; 8x430mm ; 8x440mm ; 8x450mm ; 16x460mm ; 8x480mm ; 8x500mm ; 16x520mm ; 16x540mm ; 8x560mm ;8x600mm ; 7x630mm ;8x640mm ; 8x660mm ; 8x670mm ; 8x700 ; 8x720mm ; 8x760mm ; 8x860mm

** SOLD **
