FLEXOTECNICA POLICROMA flexo press 10 colors // Flexo CI // Printing machines // Used Flexo Press // Tecno Converting 2000 S.r.l.

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Photo Gallery

Ask more informations

about a similar one

Machine Code: FL708
Manufacturer: FLEXOTECNICA
Modello: POLICROMA
Year: 2007
Number of colors: 10
Print possibilityes: 10 colours on one side
Gearless: No
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1630
Print width (mm): 1500
Min print repeat (mm): 330
Max print repeat (mm): 1100
Unwinder type: TURRET
Max reel diameter unwinder (mm): 1000
Rewinder type: TURRET
Max reel diameter rewinder (mm): 1000
Drying: Thermo iol or water
Videocamera: Videocamera AVT + Stroboscope FIFE
Vyscosity control: Yes, GAMA
Inking system: Closed chamber Doctor Blade
Anilox: 2x160 L/cm-vol 12; 2x160 L/cm-vol 9,2; 3x260-vol 5,5; 3x160-vol 6,4; 2x220-vol 6; 2x260-vol 4,0; 9x100-vol 14,5; 1x200-vol 6,5; 2x280 vol5,5; 1x380-vol 4,5; 1x400 vol 4,5; 2x100-vol 15,5; 3x100-vol 14,5; 1x360-vol 5; 1x360 vol 5,5
Print cylinders: 282 cylinders as follows: 8 x (330,340,350,360,380,410,420,440,480,510,540,550,570,600,610,620,630,650,680,710,840); 16 x (370,400); 10 x (390,580,670,830,850); 20 x 500; 12 x 660
Note: Mechanical speed: 300m/min

Machine Code	FL708
Manufacturer	FLEXOTECNICA
Modello	POLICROMA
Year	2007
Number of colors	10
Print possibilityes	10 colours on one side
Gearless	No
Fast sleeve change	Yes
4 motor per deck CNC position system	Yes
Computer supervision	Yes
Web width (mm)	1630
Print width (mm)	1500
Min print repeat (mm)	330
Max print repeat (mm)	1100
Unwinder type	TURRET
Max reel diameter unwinder (mm)	1000
Rewinder type	TURRET
Max reel diameter rewinder (mm)	1000
Drying	Thermo iol or water
Videocamera	Videocamera AVT + Stroboscope FIFE
Vyscosity control	Yes, GAMA
Inking system	Closed chamber Doctor Blade
Anilox	2x160 L/cm-vol 12; 2x160 L/cm-vol 9,2; 3x260-vol 5,5; 3x160-vol 6,4; 2x220-vol 6; 2x260-vol 4,0; 9x100-vol 14,5; 1x200-vol 6,5; 2x280 vol5,5; 1x380-vol 4,5; 1x400 vol 4,5; 2x100-vol 15,5; 3x100-vol 14,5; 1x360-vol 5; 1x360 vol 5,5
Print cylinders	282 cylinders as follows: 8 x (330,340,350,360,380,410,420,440,480,510,540,550,570,600,610,620,630,650,680,710,840); 16 x (370,400); 10 x (390,580,670,830,850); 20 x 500; 12 x 660
Note	Mechanical speed: 300m/min
