FISCHER & KRECKE 16S Flexo central drum printing press 8 colors

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL686
Manufacturer
FISCHER & KRECKE
Model
16S
Year
2002
Number of colors
8
Gearless
Yes
Fast sleeve change
Yes
Web width (mm)
1300
Print width (mm)
1250
Min print repeat (mm)
300
Max print repeat (mm)
800
Unwinder type
flying splice
Max reel diameter unwinder (mm)
1000
Rewinder type
flying splice
Max reel diameter rewinder (mm)
1000
Drying
gas
Videocamera
BST Genius
Web guides
Fife OPG edge guide before CI drum
Vyscosity control
Automatic Bloss Viscolour 1000
Washing system
F & K auto clean system
Inking system
Solvent based
Anilox
Approximately 10
Print Sleeves
4 or 5 sets
Additional information
CI drum diameter: 1910mm Chrome nickel plated Reel loading table at unwind Web tension range: maximum 350N, minimum 20N Mechanical speed: 500m/min, from 445mm repeat length Materials: PE LDPE/HDPE, PP OPP/BOPP PET, PA approximately 10-120 microns Spreader roller before CI drum Auto fresh solvent intake and used solvent emptying Drying tunnel length: 5m Web threading device Operator control OCS Carbon fibre mandrels: 3 sets
Machine Code FL686
Manufacturer FISCHER & KRECKE
Model 16S
Year 2002
Number of colors 8
Gearless Yes
Fast sleeve change Yes
Web width (mm) 1300
Print width (mm) 1250
Min print repeat (mm) 300
Max print repeat (mm) 800
Unwinder type flying splice
Max reel diameter unwinder (mm) 1000
Rewinder type flying splice
Max reel diameter rewinder (mm) 1000
Drying gas
Videocamera BST Genius
Web guides Fife OPG edge guide before CI drum
Vyscosity control Automatic Bloss Viscolour 1000
Washing system F & K auto clean system
Inking system Solvent based
Anilox Approximately 10
Print Sleeves 4 or 5 sets
Additional information CI drum diameter: 1910mm Chrome nickel plated Reel loading table at unwind Web tension range: maximum 350N, minimum 20N Mechanical speed: 500m/min, from 445mm repeat length Materials: PE LDPE/HDPE, PP OPP/BOPP PET, PA approximately 10-120 microns Spreader roller before CI drum Auto fresh solvent intake and used solvent emptying Drying tunnel length: 5m Web threading device Operator control OCS Carbon fibre mandrels: 3 sets
