FLEXOTECNICA TACHYS GL Flexo printer 8 colors

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL745
Manufacturer
FLEXOTECNICA
Model
TACHYS GL
Year
2003
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
No
Web width (mm)
1250
Print width (mm)
1200
Min print repeat (mm)
350
Max print repeat (mm)
750
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
800
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
800
Drying
2 zones - 4 fans- 2 gas burners
Videocamera
BST Premous digital
Web guides
Web guide FIFE OPG before and after the printing units
Vyscosity control
Yes automatic New Celio
Washing system
Yes
Inking system
Closed chamber doctor blades
Anilox
50 l/cm vol.16 ; 90l/cm vol.16 ; 100 v 15 , 100 v 12,5 , 140 v 13 , 160 v 13 , 160 v 11 ,
Print Sleeves
600x 9 , 580x 9 ,560x 17 ,520x 18 ,510x 10 , 540x 10 , 480x 10 , 450x 9 , 440x 9 , 430x 9 , 420x 9 , 400x 9 , 380x 9
Additional information
Plate Mounter Bieffebi year 2009
Machine Code FL745
Manufacturer FLEXOTECNICA
Model TACHYS GL
Year 2003
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision No
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 350
Max print repeat (mm) 750
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 800
Drying 2 zones - 4 fans- 2 gas burners
Videocamera BST Premous digital
Web guides Web guide FIFE OPG before and after the printing units
Vyscosity control Yes automatic New Celio
Washing system Yes
Inking system Closed chamber doctor blades
Anilox 50 l/cm vol.16 ; 90l/cm vol.16 ; 100 v 15 , 100 v 12,5 , 140 v 13 , 160 v 13 , 160 v 11 ,
Print Sleeves 600x 9 , 580x 9 ,560x 17 ,520x 18 ,510x 10 , 540x 10 , 480x 10 , 450x 9 , 440x 9 , 430x 9 , 420x 9 , 400x 9 , 380x 9
Additional information Plate Mounter Bieffebi year 2009
