8 colors BOBST SCHIAVI EF 4040 Flexo printer

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code FL713
Manufacturer BOBST SCHIAVI
Model EF 4040
Year 2006
Number of colors 8
Print possibilities 8+0
Gearless Yes
Fast sleeve change Yes
Web width (mm) 1450
Print width (mm) 1420
Max reel diameter unwinder (mm) 1000
Rewinder type Turret automatic
Drying 2 zones ,4 fans , automatic recirculation system with LEL control
Videocamera yes BST complete with register control and defect control
Corona treatment yes included AFS
Web guides in and out
Inking system closed chamber doctor blades
Anilox 13 in working conditions+ 4 to be reengraved 13 working condiions as follows , 2 x120 l/cm, 2 x 160 l/cm, 2 x 200l/cm, 1 x 240 l/cm , 2 x280 l/cm; 4 x 340 l/cm
Print Sleeves 216 sleeves as follows: 8 sleeves for each repeat as follows: 460 mm, 480mm, 500 mm,520 mm, 540, 560 , 580 , 600, 640, 660,680, 720,750, 760, 780, 800 , 810, 820, 840, 860, 880, 900,920, 960 , 980, 1010, 1020, 1040 . , ,
