FLEXOTECNICA FX8 flexo printing machine 8 colors

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL693
Manufacturer
FLEXOTECNICA
Model
FX8
Year
2010
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1050
Print width (mm)
1000
Min print repeat (mm)
300
Max print repeat (mm)
850
Unwinder type
Turret Automatic auto splice with roll lifting system
Max reel diameter unwinder (mm)
1270
Rewinder type
Turret Automatic auto splice with roll unloading system
Max reel diameter rewinder (mm)
800
Drying
2 zones 4 fans, final tunnel 4,5 mt , 2 gas burners
Videocamera
Eltrromat + Wrb Video Star 1000
Corona treatment
yes Mero
Web guides
yes in and out type Fife OPG
Washing system
yes auto wash up system
Inking system
Closed chamber doctor blades; water based inks
Anilox
8 ceramic anilox sleeves
Print Sleeves
to be confirmed
Additional information
Rotary knives slitter Helios at rewinder Paper 20-100 gsm
Machine Code FL693
Manufacturer FLEXOTECNICA
Model FX8
Year 2010
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1050
Print width (mm) 1000
Min print repeat (mm) 300
Max print repeat (mm) 850
Unwinder type Turret Automatic auto splice with roll lifting system
Max reel diameter unwinder (mm) 1270
Rewinder type Turret Automatic auto splice with roll unloading system
Max reel diameter rewinder (mm) 800
Drying 2 zones 4 fans, final tunnel 4,5 mt , 2 gas burners
Videocamera Eltrromat + Wrb Video Star 1000
Corona treatment yes Mero
Web guides yes in and out type Fife OPG
Washing system yes auto wash up system
Inking system Closed chamber doctor blades; water based inks
Anilox 8 ceramic anilox sleeves
Print Sleeves to be confirmed
Additional information Rotary knives slitter Helios at rewinder Paper 20-100 gsm
** SOLD **
