UTECO ONYX 876 flexo printing machine 8 colors

UTECO ONYX 876 flexo printing machine 8 colors
** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL669
Manufacturer
UTECO
Model
ONYX 876
Year
2007
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1450
Print width (mm)
1400
Min print repeat (mm)
380
Max print repeat (mm)
800
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
800
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
800
Drying
2 zones , 4 fans 4mt tunnel, Thermo oil heaters
Videocamera
yes
Web guides
yes in and out
Vyscosity control
yes
Washing system
yes
Inking system
Closed chamber doctor blades
Machine Code FL669
Manufacturer UTECO
Model ONYX 876
Year 2007
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1450
Print width (mm) 1400
Min print repeat (mm) 380
Max print repeat (mm) 800
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 800
Drying 2 zones , 4 fans 4mt tunnel, Thermo oil heaters
Videocamera yes
Web guides yes in and out
Vyscosity control yes
Washing system yes
Inking system Closed chamber doctor blades
** SOLD **
