9 farben OFEM ARENA GL 808-120 Flexodruck Maschine

Maschinencode FL624
Hersteller OFEM
Modell ARENA GL 808-120
Baujahr 2002
Anzahl von Farben 9
Druckoptionen 8 + 1 downstream for coating UV and water based varnishes on the same side of the web and in register with the spots printed on the CI section.
Gearless Yes
Rascher Manschettenwechsel Yes
Gewebebreite (mm) 1250
Druckbreite (mm) 1200
Max. Spulendurchmesser Abroller (mm) 1300
Aufrollertyp Single axis
Trocknung Hot air drying system. Thermic oil Heating source.
Videokamera video inspection system BST-Genius.Quick registering system at machine start up.
Gewebeführungen 1 before printing and 1 before rewinding
Druckfarbenabgabe Enclosed doctor blade chambers with ceramic anilox rollers .8 ink pumps.
Anilox Anilox sleeves ceramic coated and laser engraved as following: 1 anilox engraved to HPF-W3-140 lines/cm., volume 11 g/m2; 2 anilox engraved to HPF1-120 lines/cm., volume 10,0 g/m2; 1 anilox engraved to HPF4-220 lines/cm., volume 5,5 g/m2; 1 anilox engraved to 70 lines/cm., volume 20,0 g/m2; 3 anilox engraved to 80 lines/cm., volume 16,0 g/m2;1 anilox engraved to 100 lines/cm., volume 16,5 g/m2;2 anilox engraved to 100 lines/cm., volume 16,0 g/m2;1 anilox engraved to 110 lines/cm., volume 13,0 g/m2;2 anilox engraved to 120 lines/cm., volume 13,0 g/m2;1 anilox engraved to 140 lines/cm., volume 11,0 g/m2;1 anilox engraved to 160 lines/cm., volume 9,0 g/m2;5 anilox engraved to 180 lines/cm., volume 7,8 g/m2;5 anilox engraved to 255 lines/cm., volume 5,0 g/m2;2 anilox engraved to 300 lines/cm., volume 4,2 g/m2.
Zusätzliche Informationen Paper Registers motorized remote controlled Decks? positioning system automatic with 4 motors per deck and job repeatability program Plate roller mandrels: 8 carbon fibre plate roller air mandrels diameter 108,342 mm. for the print section; 1 plate roller air mandrels diameter 89,243 mm. for the print section.9 print sleeves to choose among those on stock (only 9 as the rest will be kept by seller). 1 downstream printing unit (this unit is a geared type) for coating water based and UV varnish in register with the Central impression section (UV lamps offered apart).
