8 farben UTECO ONYX 876 (GEARLESS) Flexodruck Maschine ** VERKAUFTE ** Weitere Informationen erbitten über eine ähnliche

Maschinencode FL622
Hersteller UTECO
Modell ONYX 876 (GEARLESS)
Baujahr 2005
Anzahl von Farben 8
Gearless Yes
Rascher Manschettenwechsel Yes
Gewebebreite (mm) 1050
Druckbreite (mm) 1000
Max. Spulendurchmesser Abroller (mm) 800
Aufrollertyp Turret automaticTA-R
Trocknung 2 gas burners. 6m lenght of the drying tunnel. 2 hot air recirculation system.
Videokamera BST type Premius Digital
Gewebeführungen BST
Druckfarbenabgabe Solvent based . 8 closed chamber doctor blade . 8 ink tray . 8 ink return system. 8 ink pumps
Anilox 25 anilox sleeves as follows 3 x 100 l/cm ?V14; 2x120 l/cm ?V12; 1x140 l/cm ?V15; 2x160 l/cm ?V10;4x200 l/cm ?V10;3x280 l/cm ?V8,51;3x300 l/cm ?V7,5;6x340 l/cm ?V5,5
Druckmanschetten 29 sets of printing sleeves ,8 sleeves each as follows: Rotec 300 , 310,315,320,330,340,350,355,360,370,380,390,400,410,420,430,440,470,480,500,520,540,560 White : 325,450 ; Red 385,460 ; Twinlock 550mm ; Biale 570mm
Zusätzliche Informationen Speed : up to 365m/min . Minimum 30m/min. Materials: PP 20-50my . Polyester 12-25my; OPP 20-55 my; BOPP 17my.Paper 40-80 gr2 . LDPE 25 -120my Tension range: 2-28 kg Plate thickness 1.14mm + 0,55 mm = 1.69 mm overall Pneumatic dancing rollers Arir expansion shaft , internal diam 76mm (2 pieces). Air expansion shaft , internal diam 152mm (2 pieces) Moorized longitudinal and side registers system remote controlled Automatic roll loading and unloading system at unwinder and rewinder Web infeed section Infeed tensioner section, type CA 012 Central Drum Hastalloy coated Central thermoregulation and cooling system Four motor print deck positioning with CNC control and final print position setting Motorized longitudinal and side register Automatic pre-register system Support roller of carbon fibre (diam 86.060mm) of the printing sleeve . Reinforced insert of a plate sleeve. 8 support roller of anilox sleeves. 8 Splash guards 1 spare closed chamber doctor blade . 1 spare ink pump Web outfeed section

** VERKAUFTE **
