FLEXOTECNICA CHRONOS Flexodruck Maschine 8 farben

Maschinencode
FL793
Hersteller
FLEXOTECNICA
Modello
CHRONOS
Baujahr
2004
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1320
Print width (mm)
1270
Min print repeat (mm)
350
Max print repeat (mm)
750
Unwinder type
Turret automatic
Max reel diameter unwinder (mm)
800
Rewinder type
Turret automatic
Max reel diameter rewinder (mm)
800
Drying
2 zones - 4 fans final tunnel -thermo oil heat exchangers - Automatric air recirculation system with LEL control
Videocamera
Yes ELTROMAT
Corona treatment
Yes FERRARINI BENELLI
Web guides
Yes in and oiut
Vyscosity control
Yes VISCOLOR 2200
Washing system
Yes
Inking system
Closed chamber doctor blades
Anilox
1x80lines ink transfer 16,4, 1x100l x 14,4, 1x120l x 13,2, 3x140l x (9,05,9,6, 11,87), 5x160l x(10.4,10.46, 10.5,10.7, 11.67), 2x260lx(6.1,7.2), 4x220lx(8.4,10,4), 2x300lx(5, 4.96), 1x260lx(7.2), 5x360lx(4.5,4.4,4.2,4.4,4.4)
Print Sleeves
4x40cm, 8x43, 7x44, 9x45, 8x46, 9x47, 8x49, 4x50, 6x51, 8x55, 10x57, 10x58, 7x62, 7x64 + 1 set of Carriers
Maschinencode FL793
Hersteller FLEXOTECNICA
Modello CHRONOS
Baujahr 2004
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1320
Print width (mm) 1270
Min print repeat (mm) 350
Max print repeat (mm) 750
Unwinder type Turret automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying 2 zones - 4 fans final tunnel -thermo oil heat exchangers - Automatric air recirculation system with LEL control
Videocamera Yes ELTROMAT
Corona treatment Yes FERRARINI BENELLI
Web guides Yes in and oiut
Vyscosity control Yes VISCOLOR 2200
Washing system Yes
Inking system Closed chamber doctor blades
Anilox 1x80lines ink transfer 16,4, 1x100l x 14,4, 1x120l x 13,2, 3x140l x (9,05,9,6, 11,87), 5x160l x(10.4,10.46, 10.5,10.7, 11.67), 2x260lx(6.1,7.2), 4x220lx(8.4,10,4), 2x300lx(5, 4.96), 1x260lx(7.2), 5x360lx(4.5,4.4,4.2,4.4,4.4)
Print Sleeves 4x40cm, 8x43, 7x44, 9x45, 8x46, 9x47, 8x49, 4x50, 6x51, 8x55, 10x57, 10x58, 7x62, 7x64 + 1 set of Carriers
** SOLD **
